Carbon

Reinforcement fibres known thanks to its low specific gravity, high resistance and great stiffness. Its more famouse precusor is PAN (polyacrylonitrile). Carbon fibres are obtained by pyrolisis at temperatures higher than 980 ºC.

The main properties of carbon fibres are the following: high Young modulus (stiffness), excellent tensile strength, electrical conductivity, great fatigue resistance, high weathering resistance and a very low CTE (Coeficient of Thermal Expansion). The very low CTE property makes these fabrics the best choice for the production of composite parts and tools produced in the oven (prepregs) at high temperatures.

Care must be taken when installig carbon composite parts together with metals as they favour galvanic corrosion of the metal. Aluminium, iron or steel must not be used. Titanium is the best choice in these cases.

Tapes
Tapes
Braided Sleeves
Braided Sleeves
Woven
Woven
Unidirectional (UD)
Unidirectional (UD)
Multiaxiales
Multiaxiales
Spread Tow
Spread Tow
Colored
Colored
Carbon tubular mesh 19 mm and 362 g / m2

Carbon Braided Sleeve of 20 mm and 362 g/m2

WFC0362
Carbon Braided Sleeve of 20 mm diameter and 362 g/m2. Ideal for the production of carbon tubes with epoxy, urethane-acrylate and vinyl ester resins.
€4.50 €5.45 Tax incl. €4.50 Tax excl.
View
Unidirectional carbon tape 175 g / m²

Unidirectional Carbon Tape of 175 g/m² (50 mm wide)

WFC0005
Unidirectional carbon tape of 175 g/m2 stitched with fiberglass in order to hold the threads together. It is used as a local structural reinforcement in composite parts made ​​of thermosetting epoxy, urethane-acrylate and vinyl ester resins.
€5.56 €6.73 Tax incl. €5.56 Tax excl.
View
3K carbon twill tape of 454 g / m2

3K Twill Carbon Tape of 454 g/m2 (60 mm wide)

WFC0051
3K twill carbon tape for local structural reinforcements using epoxy, urethane-acrylate or vinyl ester resins.
€9.30 €11.25 Tax incl. €9.30 Tax excl.
View
Carbon tubular mesh 19 mm and 362 g / m2

Carbon Braided Sleeve of 35 mm and 34 g/m for Padel Rackets

WFCTBU35MM34GM
Carbon Braided Sleeve of 35 mm and 34 g/linear meter. Ideal for the production of padel rackets and carbon tubes with epoxy, urethane-acrylate and vinyl ester resins.
€10.80 €13.07 Tax incl. €10.80 Tax excl.
View
100 g/m2 Carbon Mat, 1 m wide

100 g/m2 Carbon Mat, 1 m wide

WMATCAR5689
Carbon Mat reinforcement ideal for hand lay-up and infusion laminates with any kind of thermosetting resin: epoxy, urethane-acrylate or vinyl ester.
Last items in stock
€12.00 €14.52 Tax incl. €12.00 Tax excl.
View
25 g/m lineal 3K Carbon Braided Sleeve, diameter 45 mm

25 g/m 3K Carbon Braided Sleeve, diameter 45 mm

FC2016-45
Carbon Braided Sleeve ideal for the production of carbon tubes with epoxy, urethane-acrylate and vinyl ester resins. Diameter: 45 mm. Aerial weight: 25 g/linear m
€13.50 €16.34 Tax incl. €13.50 Tax excl.
View
Carbon tubular mesh 19 mm and 362 g / m2

12K Carbon Braided Sleeve, diameter 70 mm

FC0070
Carbon Braided Sleeve of 70 mm. Ideal for the production of carbon tubes with epoxy, urethane-acrylate and vinyl ester resins. Aerial weight: 29,8 g/m
€15.50 €18.76 Tax incl. €15.50 Tax excl.
View
100 g/m2 Carbon Mat, 1 m wide

300 g/m2 Carbon Mat, 1 m wide

WMATCAR5690
Carbon Mat reinforcement ideal for hand lay-up and infusion laminates with any kind of thermosetting resin: epoxy, urethane-acrylate or vinyl ester.
€16.75 €20.27 Tax incl. €16.75 Tax excl.
View
3K 240 gsm Plain Carbon Fiber Tape Taffeta (25 mm wide)

3K 240 gsm Plain Carbon Fiber Tape Taffeta (25 mm wide)

CCARB240
3K Plain carbon tape for structural reinforcement using epoxy, urethane-acrylic or vinylester resins. Carbon yarn type: 3K (3000 filaments per strand) and 200 tex Weight: 240 g/m2
Out-of-Stock
€18.00 €21.78 Tax incl. €18.00 Tax excl.
View
150 g/m2 HS Biaxial Carbon Fabric 12 K, 27 cm width SPOT

150 g/m2 HS Biaxial Carbon Fabric 12 K, 27 cm width SPOT

TCBX15012K/27
150 g/m2 12K biaxial carbon fabric for high performance applications where high strength and low weight are required. Produced with two 75 g/m2 layers of unidirectional fabric, oriented at +45° and -45°.Roll width: 27 cm.
€23.00 €27.83 Tax incl. €23.00 Tax excl.
View
200 g/m2 C-WEAVE Carbon Fabric 2x2 Twill 3K SPOT, 125 cm width

200 gsm Twill 2x2 Carbon Fabric C-WEAVE 200T/3 3K HS SPOT, 125 cm width

TC200S3K
Twill carbon fabric for high performance applications where high strength and low weight is required. Compatible with all type of thermosetting resins such us polyester, urethane-acrylate, vinyl ester and epoxy. Suitable for hand lay-up, infusion or RTM (Inyection). Roll width: 125 cm Manufacturer: Chomarat
Out-of-Stock
€24.00 €29.04 Tax incl. €24.00 Tax excl.
View
Unidirectional Carbon fabric 24 K and 300 g / m2

Unidirectional Carbon fabric 24 K and 300 g/m2, width 60 cm

WTCU300UQ
Unidirectional Carbon fabric 24 K and 300 g/m2 is suitable for production of composite parts and tools with epoxy, vinyl ester and urethane-acrylic (Crestapol) resins. Ideal for specific reinforcements in certain directions of the composite part or tool. Supplied covered with a protective and sealing plastic film.
Out-of-Stock
€25.00 €30.25 Tax incl. €25.00 Tax excl.
View
Unidirectional Carbon fabric 24 K and 300 g / m2

Unidirectional Carbon fabric 24 K and 300 g/m2, width 63 cm

WTCU300UQ/63
Unidirectional Carbon fabric 24 K and 300 g/m2 is suitable for production of composite parts and tools with epoxy, vinyl ester and urethane-acrylic (Crestapol) resins. Ideal for specific reinforcements in certain directions of the composite part or tool. Supplied covered with a protective and sealing plastic film.
Last items in stock
€26.35 €31.88 Tax incl. €26.35 Tax excl.
View
Unidirectional carbon fabric 600 g / m2

Unidirectional Carbon Fabric 50K and 600 g/m2

WFC600U
Unidirectional carbon fabric 50K of 600 g/m2 and 50 cm wide. Suitable for producing composite parts and tool with epoxy, urethane-acrylate or vinyl ester resins. Especially used for one direction structural reinforcements.
€27.00 €32.67 Tax incl. €27.00 Tax excl.
View
300 g/m2 12K Biaxial Carbon Fabric (+45/-45º) Saertex® X-C-302, 945 mm wide

300 g/m2 12K Biaxial Carbon Fabric (+45/-45º) Saertex® X-C-302, 945 mm wide

TCBX302-945
300 g/m2 biaxial carbon fabric for high performance applications where high strength and low weight are required. Produced with two 150 g/m2 layers of unidirectional fabric, oriented at +45° and -45°. Thanks to its Toray general purpose sizing (nº 5) it is a suitable carbon fabric for the manufacturing of composite parts and tools with epoxy,...
€28.00 €33.88 Tax incl. €28.00 Tax excl.
View
200 g/m2 C-WEAVE Carbon Fabric 2x2 Twill 3K SPOT, 125 cm width

200 gsm Twill 2x2 Spread Tow Carbon Fabric C-WEAVE SP 200T/1 3K HS SPOT, 125 cm width

TCSP200T/125
C-WEAVE™ SP 200T/1 3K HS is a 200 gsm spread-tow carbon fabric. It has 4.9 warp threads/cm and 5 weft threads/cm. It is made using a 2/2 twill weave. The thread is a 3K carbon thread (3000 filaments). This fabric has a closed surface (more than 99%) and is intended for applications where appearance is important. Roll width: 125 cm Manufacturer: Chomarat
Out-of-Stock
€28.00 €33.88 Tax incl. €28.00 Tax excl.
View
300 gsm Biaxial Carbon Fabric +45/-45º C-PLY™ SP BX 300 C2,5 24K T620S, width 127 cm (SPOT)

300 gsm Biaxial Carbon +-45º C-PLY™ SP BX 300 24K T620S (epoxy binder fixation), width 127 cm (SPOT)

300 g/m2 biaxial carbon fabric for high performance applications where high strength and low weight are required. Produced with two 150 g/m2 layers of unidirectional fabric, oriented at +45° and -45°. Suitable for manufacturing of composite parts and tools with epoxy, urethane-acrylate or vinyl ester resins by hand lay-up, infusion or RTM.
Out-of-Stock
€29.00 €35.09 Tax incl. €29.00 Tax excl.
View
314 gsm 0º Unidirectional 50K Saertex Carbon Fibre Cloth

314 gsm 0º Unidirectional 50K Saertex® Carbon Fibre Cloth, 1230 mm wide

TCUD314
Saertex unidirectional 314 gsm carbon fabric for high performance applications where high mechanical resistance and low weight are required. Manufactured with a layer of 300 sqm unidirectional fabric Zoltek Panex 35-13 of 50K, oriented at 0º and sewn with a 68 gsm E-glass fabric of 68 Tex in the 90º direction. Ideal for combining with epoxy,...
€29.50 €35.70 Tax incl. €29.50 Tax excl.
View
650 g/m2 12 K 2x2 Twill Carbon fabric SPOT, 125 cm wide

650 gsm 12 K 2x2 Twill Carbon fabric SPOT, 125 cm width

TC650S12K
12 K, 2x2 Twill Carbon fabric of 650 g/m2 for high performance applications where high strength and low weight are required. Ideal for producing epoxy, vinyl ester and urethane-acrylate composite parts or tools by hand lay-up, infusion or RTM/ RTM light. SPOT carbon fabrics are special offers at a cheaper price that we cannot always guarantee the offer in...
Out-of-Stock
€29.95 €36.24 Tax incl. €29.95 Tax excl.
View
280 g/m2, Satin 6K C-Weave 280SA5 Carbon Fabric, 125 cm width (SPOT)

280 g/m2, Satin 6K C-Weave 280SA5 Carbon Fabric, 125 cm width (SPOT)

TC2806KSaten
C-WEAVE™ 280SA5 T800 HB 6K is a 280 gsm carbon fabric. It has 6.2 warp threads/cm and 6.2 weft threads/cm. It is made using a 5-H satin weave, resulting in a very dense weave with good drape. The thread is a 6K intermediate modulus carbon thread. Designed initially for the aerospace industry, this reinforcement is also used for parts in Formula 1 cars and...
Out-of-Stock
€30.00 €36.30 Tax incl. €30.00 Tax excl.
View
