Sphere.core PSI 2 mm for Vaccum Infusion and RTM

SCOREPSI2-1
8 Items
€22.00
€26.62 Tax incl. €22.00 Tax excl.
Tax excluded

By buying this product you can collect up to 2 point points. Your cart will total 2 points that can be converted into a voucher of €0.20.

This core material with internal flow medium was developed to meet highest demands in RTM and VIP processes. It is characterized by excellent flow properties. The internal flow medium saves vacuum consumables and waste.

Choose the type of supply



 Calculate Shipping Cost
Ratings and comments from our customers
( 0.0 / 5) - 0 feedback(s)

Sphere.core PSI is a core designed for closed mold process.

This core material with internal flow medium was developed to meet highest demands in RTM and VIP processes. It is characterized by excellent flow properties. The internal flow medium saves vacuum consumables and waste.

Width: 127 cm

Resin consumption: 0.66 kg/m2

Base material

Glass veil, volumized with thermoplastic microspheres and needled polypropylene fibers.

Characteristics

  • Core material with flow medium
  • For closed mold process
  • Excellent resin flow
  • For all resin systems
  • For vacuums up to 0,9 bar

Process

  • RTM
  • RTM light
  • VIP core infusion

Properties

• Fibreglass-based material
• No external flow medium needed
• Low resin uptake
• No honeycomb structure
• High shear strength

Advantages

• Fast and steady impregnation
• Strong, rigid and robust laminate
• Less effort and waste
• Suitable for high vacuum
• Perfect surface

Technical information

PSI 2,0 mm PSI 3,0 mm PSI 4,0 mm PSI 5,0 mm
Thickness [mm] 2,0 3,0 4,0 5,0
Resin uptake [kg/m²] 0,66 0,99 1,32 1,65
Density of core [g/m³] 470 450 420 390

Type of supply

Sphere.core PSI 2 mm x 1 m2, supplied rolled in cardboard tube and box

Sphere.core PSI 2 mm x 5 m2, supplied rolled in cardboard tube and box

Sphere.core PSI 2 mm x 25 m2, supplied rolled in cardboard tube and box

Sphere.core PSI 2 mm x 88,90 m2, supplied rolled in plastic film
