200 gsm Glass-Epoxy Prepreg Alutex MTP305 V-202T-33%RW, width 1270 mm

Introduction

Alutex MTP305 V-202T is a glass prepreg manufactured with a high transparency modified epoxy resin. It is suitable for aesthetic carbon composite parts where high cosmetical requirements are needed. The epoxy resin MTCV305 can be used with carbon or metallic mould with the standard technologies: Hot Press, Wrapping, Autoclave and Vacuum Bag.

Benefits and Features

• Applications: automotive, sport goods, marine, industrial, and so forth.
• Different curing cycles possible.
• Good mechanical properties
• UV resistance improved

Resin properties

Curing Cycles Suggested

2 hours at 110 ºC for a final Tg (TanDelta DMA, ºC) of 120-125 ºC

1 hour at 125 ºC for a final Tg (TanDelta DMA, ºC) of 120-125 ºC

Roll width: 1270 mm

Type of glass yarn: E Glass EC 9 68 tex both in warp and weft

Type of glass fabric: 200 g/m2 2x2 Twill

Epoxy Resin Key Features & Benefits

• Cure temperature from 110°C to 125°C
• Service temperature up to 125°C after post cure
• Low shrinkage
• Out life at 23°C: 5 weeks
• Shelf-life at -18°C: 12 months
• Very low VOC content – no added solvents during manufacture

Snap cure available fot hot press moulding - details in the technical data sheet

Type of supply

200 gsm Twill Glass-Epoxy Prepreg  MTP305 V-202T-33%RW, Width 1270 mm x 1 m2, supplied rolled in cardboard box

200 gsm Twill Glass-Epoxy Prepreg  MTP305 V-202T-33%RW, Width 1270 mm x 5 m2, supplied rolled in cardboard box

200 gsm Twill Glass-Epoxy Prepreg  MTP305 V-202T-33%RW, Width 1270 mm x 25 m2, supplied rolled in cardboard box

200 gsm Twill Glass-Epoxy Prepreg  MTP305 V-202T-33%RW, Width 1270 mm x 50 m2, supplied rolled in cardboard box
